Whirlpool Duet/Kenmore HE3 Front-Load Washer Disassembly

---

Reference Model: WFW9400SW03

---

Repairing a Whirlpool Duet or Kenmore HE3 front-loading washer. This video demonstrates the proper and safe way to disassemble a washing machine and how to access parts that may need to be tested and/or replaced.

---

CLICK the picture---->

---

Some washing machine parts for our reference model#

Washing machine door boot

Item Number WP8182119

Washing machine drain pump assembly

Item Number 280187

Door hinge

Item Number WP8183202

Door lock/latch assembly for front load washer

Item Number WP8183270

---

Kenmore/Whirlpool Washing Machine Parts

---

---
